Product Introduction
- Grade 5 titanium bar for aerospace use is selected when high strength, low weight, corrosion resistance, and machining consistency are required in the same project. It is widely used as starting material for machined aerospace parts, structural connectors, fastener components, shafts, and other load-bearing parts.
- Compared with general industrial titanium bars, aerospace projects pay more attention to traceability, material consistency, dimensional control, and inspection requirements. For this reason, Grade 5 titanium bar is commonly supplied to ASTM B348 or AMS 4928, with diameter, length, surface condition, and inspection scope confirmed according to the actual drawing or purchase specification.
Product Parameter
| Parameter | Typical Supply |
| Material Grade | Grade 5 Titanium / Ti-6Al-4V / UNS R56400 |
| Standard | ASTM B348 or AMS 4928 |
| Diameter Range | Ø6-250 mm |
| Length | 50-6000 mm |
| Supply Condition | Annealed |
| Surface Finish | Turned / Ground / Polished |
| Tensile Strength | ≥895 MPa |
| Yield Strength | ≥825 MPa |
| Elongation | ≥10% |
| Inspection | Chemical analysis, mechanical testing, dimensional inspection |
| Optional Testing | UT to AMS 2631 when required |
| Documentation | MTC and heat traceability |
Product Features & Application
- Aerospace Structural Components
Grade 5 titanium bar is commonly used as starting material for machined aerospace brackets, pins, connectors, and other structural parts where high strength and lower component weight are required together.
- Precision Machined Aerospace Parts
Aircraft brackets, clevises, hinge pins, actuator links and other load-path components are commonly machined from Grade 5 bar when weight reduction must be achieved without reducing section strength.
For repeat aerospace parts, buyers should confirm stock allowance, straightness over the inspection length, cut-end condition and whether multiple pieces must be supplied from the same heat.
- Inspection for Aerospace Orders
Heat-lot continuity, MTC and agreed mechanical test records are more relevant to this page than general corrosion statements.
When ultrasonic inspection is required, the inspection method, acceptance class and reporting scope should be stated in the purchase order before production.
Product Details
- Material: Grade 5 Titanium / Ti-6Al-4V / UNS R56400
- Standard: ASTM B348 or AMS 4928
- Diameter Range: Ø6-250 mm
- Length: 50-6000 mm, including cut-to-length supply
- Surface: Turned, ground or polished according to machining needs
- Supply Condition: Annealed
- Processing Options: Chamfered ends, fixed-length cutting and machining allowance
- Inspection: Chemical analysis, mechanical testing, dimensional check, optional UT
- Documents: MTC and heat traceability
After-Sales Service
What We Support
- Specification Review
Material grade, standard, diameter, length, surface condition, and inspection scope are checked before production.
- Documentation Support
MTC, heat number, and agreed inspection records can be supplied with the order.
- Machining Preparation
Cut length, end condition, and machining allowance can be arranged according to the downstream process.
- Order Flexibility
Sample orders, trial orders, and regular production quantities can all be discussed based on project needs.
- Quality Follow-Up
Any issue related to material, dimensions, or surface condition can be checked against the order records and inspection data.
FAQ
Q1: How is straightness guaranteed?
A1: Each Gr5 Titanium Bar is measured with laser alignment equipment. We maintain ≤5 μm deviation per 300 mm, preventing misalignment and eliminating costly rework during assembly.
Q2: Can I request non-standard lengths?
A2: Yes, we cut bars to the required size before dispatch. This minimizes waste in your workshop and reduces overall machining costs.
Q3: What length tolerance can you provide?
A3: Standard cutting tolerance is ±1 mm. For aerospace projects requiring tighter control, we can achieve ±0.5 mm on request, helping reduce finishing work on your side.
Company profile
Baoji Zhongxinbao Metal Materials Co., Ltd. supplies Grade 5 titanium bar for aerospace machining, structural components, and other high-strength industrial applications. Our processing capabilities cover cutting, turning, grinding, polishing, and dimensional inspection, supporting both standard sizes and custom requirements.
Orders can be arranged according to ASTM B348 or AMS 4928 requirements, with material certification, heat traceability, and agreed inspection documents supplied with the shipment. We focus on practical communication during quotation and production so that diameter, length, surface condition, and inspection scope match the actual project requirement more clearly.
